Product Code:
100BR1699
PALLET JACK 2500KGCAP EUROLIFTER BRAND.
1150MM LONG FORKS-MINIMUM HEIGHT 85MM -
685MM WIDE FORKS MAX FORK HEIGHT:195MM.
|
|
|
|
|
|
|
 |
|
|
|
EUROLIFTER BRAND PALLET TRUCK - 2500KG MADE IN EUROPE
NOTE: MADE FOR MOST TYPES OF CONCRETE & TILE FLOORS (RED POLYURETHANE WHEELS )
NEW: WELDED PUMP - INTEGRATED FOOT PUMP RELEASE - SLIP FREE HANDLE !!!
KITS AVAILABLE FOR LIFT PUMP. PART NUMBER 12601805 NOTE 2010 ONWARDS
PALLET TRUCK PUMP IS GALVANIZED & WELDED ON NEW MODEL 15/8/2018
FORK OVERALL WIDTH (TOTAL): 685MM
LENGTH OF FORKS: 1150MM
CENTRE FORK WIDTH (GAP): 365MM
MINIMUM HEIGHT: 85MM
MAXIMUM LIFT HEIGHT: 200MM
REAR FORK TWIN POLYURETHANE WHEELS: 180MM O.D X 30MM WIDE WITH 20MM BORE
FRONT POLYURETHANE ROLLERS SIZE 95MM WIDE X 75MM ROUND WITH 20MM BORE
LOAD CAPACITY: 2,500 KG
MADE IN EUROPE
FRONT WHEELS: SINGLE POLYURETHANE WHEEL
THIS IS OUR PREMIUM PALLET JACK IN OUR SYSTEM AND HAS BEEN FOR A NUMBER OF YEARS WITH NO PROBLEMS WHATSOEVER. OVERHAUL KIT AVAILABLE FOR LIFT PUMP. PART NUMBER 12601805 (THIS IS FOR THE SILVER PUMP ONLY FROM 2010 ONWARDS)
RED POLYURETHANE WHEELS
SAFETY PRECAUTIONS -
WARNING: FAILURE TO HEED THE FOLLOWING WARNINGS CAN RESULT IN PERSONAL INJURY AND/OR EQUIPMENT DAMAGE.THESE WARNINGS CANNOT COVER EVERY SITUATION, SO HAVE SAFETY FOREMOST IN YOUR MIND WHEN SETTING UP A JOB.
- READ, UNDERSTAND AND FOLLOW THE OPERATING INSTRUCTIONS AND THE ANSI B30.1 AND ASME PALD-1 SAFETY STANDARDS FOR JACKS. IF THE OPERATOR CANNOT READ ENGLISH, OPERATING INSTURCTIONS AND SAFETY PRECAUTIONS MUST BE READ AND DISCUSSED IN THE OPERATOR'S NATIVE LANGUAGE.
- WEAR EYE PROTECTION THAT MEETS THE REQUIREMENTS OF ANSI Z87.1 AND OSHA.
- INSPECT THE JACK BEFORE EACH USE; DO NOT USE THE JACK IF IT IS DAMAGED, ALTERED, OR IN POOR CONIDITION.
- TO PREVENT TIPPING, SET UP THE JACK ON A HARD, LEVEL SURFACE. SET VEHICLE PARKING BRAKE AND BLOCK TYRES.
- THE LOAD MUST NOT EXCEED THE RATED LIFTING CAPACITY OF THE JACK. LIFT ONLY DEAD WEIGHT.
- CENTER THE LOAD ON THE JACK SADDLE, BECAUSE OFF-CENTRE LOADS CAN DAMAGE SEALS AND CAUSE HYDRAULIC FAILURE.
- USE THE JACK FOR LIFTING PURPOSES ONLY. THIS JACK IS DESIGNED TO LIFT LOADS, NOT SUPPORT LOADS. IMMEDIATELY SUPPORT A LIFTED LOAD WITH JACK STANDS.
- STAY CLEAR OF LIFTED LOADS.
- USE ONLY APPROVED HYDRAULIC FLUID, SUCH AS CHEVRON AW HYDRAULIC OIL MV OR EQUIVALENT.
- THE JACK SHOULD BE USED ON HARD, LEVEL SURFACES
- THE WHEELS OF THE VEHICLE TO BE CHOCKED
- DO NOT PUT A PORTION OF YOUR BODY UNDER A VEHICLE SUPPORTED BY A JACK
- NO PERSON SHOULD REMAIN IN A VEHICLE THAT IS BEING JACKED
- DO NOT EXCEED THE WORKING LOAD LIMIT
OPERATING INSTRUCTIONS -
TO RAISE THE JACK, USE NARROW END OF JACK HANDLE TO TIGHTEN RELEASE VALVE CLOCKWISE (CW). INSERT HANDLE INTO SOCKET AND OPERATE PUMP. TO LOWER THE JACK, SLOWLY OPEN THE RELEASE VALVE KNOB BY TURNING IT COUNTERCLOCKWISE (CCW).
|
