Product Code:
K2706-3
*K* ENGINE DRIVE LINCOLN 185 WELDER
OUTBACK 185 MODEL-5700 WATTS PEAK
KOHLER LARGE 25.7LITRE FUEL TANK LINCOLN
|
|
|
|
|
Please enter a valid quantity |
|
|
|
|
 |
|
|
|
- THE OUTBACK® 185 ENGINE DRIVEN WELDER HAS PORTABLE DC STICK WELDING WITH AC GENERATOR POWER.
- LOW-LIFT GRAB BARS (PATENT PENDING)
- ALL ENGINE CONTROLS ON FRONT CONTROL PANEL
- 32 MM DIAMETER RUGGED TUBE FRAME
- 25.7 LITRE FUEL TANK
BUILT FOR THE OUTDOORS!
GREAT FOR ANYONE WHO NEEDS PORTABLE DC STICK WELDING AND AC GENERATOR POWER! THE LOW-LIFT GRAB BARS ON BOTH ENDS MAKE LIFTING THE OUTBACK® 185 ON AND OFF TRUCK BEDS EASY. THE COMPACT OUTBACK® 185 IS EASY TO START WITH ALL ENGINE CONTROLS ON THE FRONT OF THE MACHINE, AND IT'S EASY TO USE FOR WELDING. USE THE AC GENERATOR POWER FOR A VARIETY OF APPLICATIONS DESCRIBED BELOW WITH THE LARGE 25.7 LITRE FUEL TANK! PLUG IN A LINCOLN ELECTRIC POWER MIG® 180C FOR WIRE WELDING TOO.
LOW-LIFT GRAB BARS (PATENT PENDING)
- MORE LEVERAGE FOR LIFTING UNIT ON AND OFF TRUCK BEDS.
- EXTRA PROTECTION AGAINST PRODUCT DAMAGE.
- BEST IN CLASS FEATURE!
ALL ENGINE CONTROLS ON FRONT CONTROL PANEL
- EASY ACCESS FOR STARTING, ESPECIALLY WHEN MOUNTED ON TRUCK BEDS.
- FRONT PANEL INCLUDES ELECTRIC START SWITCH AND ENGINE CHOKE CONTROL.
- BEST IN CLASS FEATURE!
32MM DIAMETER RUGGED TUBE FRAME
- GREAT FOR ALL-AROUND STURDY PROTECTION.
- BEST IN CLASS FEATURE!
25.7 LITRE FUEL TANK
- LESS FREQUENT RE-FUELING, FOR EXTENDED RUN TIMES.
- LARGE FUEL FILL OPENING FOR EASY RE-FUELING TOO!
- BEST IN CLASS FEATURE!
WELD WITH UP TO 4 MM STICK ELECTRODE
- UP TO 185 AMPS OF DC OUTPUT FOR MANY APPLICATIONS.
5,700 WATTS PEAK AC GENERATOR POWER (5,200 WATTS CONTINUOUS).
- MANY USES! GRINDER, WORK LIGHTS, PUMP, MOTOR STARTING, OR EMERGENCY POWER.
- PLUG IN A LINCOLN ELECTRIC POWER MIG® 180C FOR WIRE WELDING.
- PLUG IN A LINCOLN ELECTRIC INVERTEC® PC-210 AIR TO CUT METAL.
SPECIFICATIONS:
RATED OUTPUT:
- 130AMPS DC/25V/60%
- 150AMPS DC/25V/20%
OUTPUT RANGE: 50-185A DC
GENERATOR OUTPUT: 5700 WATTS PEAK, 5200 WATTS CONTINUOUS
TYPE OF ENGINE: KOHLER CH440 (PETROL)
HP AND SPEED: 14 HP @ 3600 RPM
CYLINDERS: 1
DIMENSIONS (HEIGHT X WIDTH X DEPTH): 651MM X 536MM X 800MM
NOISE LEVEL:
- 103.3 DB SOUND POWER (LWA)
- 78.9 DBA SOUND LEVEL AT 7METRE
|
