Product Code:
HDBC20
WORKSHOP 6/12/24V 20A* 12,000MA BATTERY
CHARGER MANUAL & AUTO
BATTERY CHARGER 6/12/24 VOLT START TIMER
|
|
|
|
|
Please enter a valid quantity |
|
|
|
|
 |
|
|
|
MANUAL & AUTOMATIC
INPUT: 240V, 50Hz, 300W
- 12,000MA BATTERY CHARGER @ 6 AND 12 VOLT
- 12,000MA AT 6 VOLTS, 12,000MA AT 12 VOLTS, 7,700MA @24 VOLTS
- ENGINE START 3 CYCLES 5 MINUTES ON 20 MINUTES OFF
- 6 VOLT = 50A AT 3.6V
- 12 VOLT = 50 A AT 7.2V
- 24 VOLT = 25 A AT 14.4V
- LED CHARGE INDICATOR
- AUTOMOTIVE: VOLTAGE 6, 12, 24V, BATTERY SIZE: 450-1200CCA, CHARGE TIME: 6-15 HOURS
- MARINE: VOLTAGE 6, 12, 24V, BATTERY SIZE: 600 TO 1400MCA, CHARGE TIME: 8 TO 18 HOURS
- DEEP CYCLE: VOLTAGE: 6, 12, 24V, BATTERY SIZE: 65 TO 160AH, CHARGE TIME 8 TO 18 HOURS
FEATURES:
- MULTI VOLTAGE OPERATION
- SUITABLE FOR CHARGING 6, 12 OR 24 VOLT BATTERIES.
MANUAL CHARGE:
- WHEN USED BY EXPERIENCED OPERATORS, IT CAN BE USED TO DELIVER AN EQUALIZATION CHARGE TO BALANCE THE VOLTAGE - IN THE BATTERY'S CELL.
AUTOMATIC CHARGE:
- LEAVE CONNECTED TO THE BATTERY WITHOUT THE RISK OF OVERCHARGING. THE CHARGER AUTOMATICALLY CONTROLS ITS - OUTPUT WHEN THE BATTERY IS FULL AND MAINTAINS IT IN A FULLY CHARGED STATE.
0-14 HOUR TIMER:
- AUTOMATICALLY TURNS THE BATTERY CHARGER OFF AFTER SET TIME. CAN BE SET AT 60 MINUTE INTERVALS.
ENGINE START:
- IF YOU NEED TO GET GOING AND THE BATTERY IS FLAT, THEN THE ENGINE START WILL HELP YOU OUT. CONNECT THE - CHARGER TO THE BATTERY, SET IT TO ENGINE START MODE FOR 5 MINUTES, THEN START YOUR ENGINE.
L.E.D. VOLTAGE/AMP DISPLAY:
- A VOLT METER DETERMINES THE BATTERY CHARGE LEVEL WHILE THE AMP METER DISPLAYS HOW MUCH POWER IS BEING - DELIVERED INTO THE BATTERY.
THERMAL OVERLOAD/POLARITY PROTECTION:
- PREVENTS THE OUTPUT LEADS FROM SPARKING DUE TO ACCIDENTAL REVERSE CONNECTION OR SHORT CIRCUIT, INCREASING SAFETY.
|
