RED ROTATING LASER LEVEL KIT GRADE
Click on image for larger photo
Product Code: 012-I88RK

RED ROTATING LASER LEVEL KIT GRADE
600MTR DIAMETER- MM RECEIVER 9AH BATTERY
SCAN-SLOPE & RTM RECEIVER DOWN TO 1/2 MM
Border Image Border Image
Shop Price: $1,699.00
Web Price: $1,699.00  inc tax

Availability: In Stock
Quantity:
Weight: 5 KG

Border Image Border Image
WITH SELF-LEVELLING, GRADE SLOPE FUNCTION, SCAN MODE, HORIZONTAL AND VERTICAL, REMOTE CONTROLLER AND 9AH LITHIUM-ION
MM DIGITAL DETECTOR BATTERY THE IMEX RANGE REPRESENTS EXCELLENT VALUE WITH VERSATILE CAPABILITIES FOR A FULL RANGE OF CONSTRUCTION FUNCTIONS. COMBINED WITH THIS IS THE HIGHLY VISIBLE HEAVY DUTY AND ROBUST, WATER AND DUST-PROOF CASE, WITH A FULLY ENCLOSED LASER DIODE FOR YEARS OF TROUBLE-FREE USE. A SENSOR BASED SELF-LEVELLING SYSTEM UTILIZING A LEVEL SENSOR AND STEPPING MOTOR GIVES EXCELLENT LEVELLING ABILITY AND ENHANCED ACCURACY.
THE SIMPLIFIED DESIGN ELEMENTS AND ROBUST COMPONENTRY ALSO MEAN REDUCED CALIBRATION AND SERVICE REQUIREMENTS. ALL BACKED BY IMEX WARRANTY, SERVICE AND INNOVATIVE APPROACH.

ROBUST CONSTRUCTION TOUGH HORIZONTAL/VERTICAL LASER LEVEL.
HORIZONTAL/VERTICAL SELF LEVELLING (ELECTRONIC). 600M RANGE. DUAL MANUAL GRADE SLOPE.
9AH LITHIUM-ION BATTERY ? APPROX. 40 HOURS RUN TIME
USB QUICK CHARGE PORT WITH CAR CHARGER
LRX10 DIGITAL DETECTOR IN MM READING (GERMAN MADE)
90MM DETECTOR READING ULTRA FINE, FINE, MEDIUM, COURSE AND ULTRA COURSE.

SCAN MODE ? ALLOWS FOR PART BEAM ROTATION IN SELECTED WORKING ENVIRONMENTS, I.E. ON INTERIOR WALLS, BUSY WORK-SITES WHERE OTHER LASER INTERFERENCE MAY BE PRESENT. VARIOUS SCAN LENGTHS AND ROTATION PLACEMENT.

DUAL GRADE ? GRADE SLOPE TO 5° (8.8%) IN TWO DIRECTIONS, X AND Y AXIS SIMULTANEOUSLY FOR TRUE GRADE CONTROL. IDEAL FOR PIPE LAYOUT OR CONCRETE SLAB FALLS.

PLUMB SPOT ? TOP AND BOTTOM PLUMB SPOT BEAM TO ASSIST IN SET UPS OVER A POINT.
ACCURACY ? +/- 1.5MM @ 30 METRES FOR EXCELLENT RESULTS EVERY TIME.
REMOTE CONTROL PANEL ? ALLOWS GRADE OR OTHER FUNCTIONS TO BE CARRIED OUT UP TO 20 M AWAY FROM THE INSTRUMENT, FOR TRUE ONE-MAN OPERATION AND GREATER EFFICIENCY.
HI-VISIBILITY CASE ? UNIQUE IMEX FEATURE, EASY TO SEE ON THE BUSIEST CONSTRUCTION SITE, MINIMISES THE RISK OF THE UNIT BEING BUMPED, INCREASING SAFETY AND ACCURACY.
includes staff and tripod

SPECIFICATIONS:
SELF LEVELLING RANGE +/- 5°
ACCURACY 1.5 MM @ 30 M
WORKING DISTANCE 600 M DIAMETER
FUNCTION HORIZONTAL / VERTICAL
SCAN MODE YES, 0°, 10°, 45°, 90°, 180°
SLOPE MODE YES - DUAL MANUAL GRADE TO 5° 8.8%
ROTATION SPEEDS 0, 60, 120, 300, 600 RPM
LIGHT SOURCE RED 635NM CLASS II
WATER RESISTANT, SHOCKPROOF IP66
POWER SOURCE 9 AH 3.7V LITHIUM-ION
WORKING TIME CONTINUOUS USE 40 HRS APPROX RED
CHARGING TIME 4 HRS IN UNIT OR REMOVED FROM UNIT
USBC CHARGING YES; INCLUDING 12V CAR CHARGER
HIGH WIND SENSITIVITY RE-SET YES
REMOTE CONTROL YES, ICR8
WEIGHT-UNIT ONLY 2.48 KG
DETECTOR - GERMAN MADE LRX10 DOUBLE SIDED
DETECTOR PICK-UP 90MM -30MM TO +60MM
DETECTOR READING ULTRAFINE - 0.5MM
FINE - 1.0MM
MEDIUM - 2.0MM
COURSE - 5.0MM
ULTRA COURSE - 10.0MM
DETECTOR POWER 1-AA > 50 HRS RUN
