Product Code:
WO-3250A
MAGNETIC DRILL CAP 12-32MM COOLANT TANK
MAX THICKNESS 50MM STEEL AUTO / MANUAL
FEED, HANDLE - LED INDIC- NITTO
|
|
|
|
|
Please enter a valid quantity |
|
|
|
|
 |
|
|
|
NITTO MAGNETIC DRILL CAPACITY 12-32MM WITH COOLANT TANK
FROM THE EXTREMELY EFFICIENT ELECTRO-MAGNET TO THE HEIGHT ADJUSTABLE FRAME WITH REVERSIBLE FEED HANDLES, THE NEW ATRA ACE IS MORE COMPATIBLE TO USER NEEDS WHILE OFFERING GREATER OPERATOR SAFETY.
ORIGINAL OZBROACH CUTTERS DRASTICALLY SHORTEN DRILLING TIME WHEN COMPARED TO SIMILAR SIZED CONVENTIONAL TWIST DRILLS. AN OPTIONAL ONE-TOUCH KEYED CHUCK ALLOWS THE USE OF UP TO 12MM TWIST DRILLS.
NEWLY DEVELOPED OVER-LOAD SHUTDOWN, MAGNET OPEN-CIRCUIT SENSOR, AND FAIL-SAFE RESTART TECHNOLOGY FORMERLY ONLY FOUND ON HIGH-END NITTO KOHKI AUTOMATICS IS INCORPORATED ON THE MACHINE TO FURTHER INCREASE DRILL OUTPUT WHILE KEEPING COSTS DOWN AND SAFETY PARAMOUNT.
FEATURES:
OVERLOAD DETECTION WITH LED INDICATOR
ADVANCE MOTOR DESIGN
MAGNET SWITCH PROTECTOR
FAIL SAFE RESTART
REVERSABLE FEED HANDLE
COOLANT TANK
CARRY CASE
HOLE CAPACITY DIA 12-32MM
MAXIMUM THICKNESS 50MM
MAGNETIC HOLDING 900 KG/F POWER
APPLICATIONS:
ON-SITE HOLE CUTTING IN STEEL PLATES, H-BEAMS SHAPED BARS, FRAMEWORK, SHIPBUILDING, BRIDGE CONSTRUCTION AND REPAIR, STEEL REINFORCEMENTS, AND MANY OTHER METAL WORKING AND CONSTRUCTION JOBS.
SPECIFICATIONS:
POWER SOURCE (SINGLE PHASE): 220~240V AC 50-60HZ
RATED POWER CONSUMPTION: 950W
RATED CURRENT: 4.3A
NO LOAD SPEED: 530RPM
MAGNETIC POWER CONSUMPTION: 70W
MAGNETIC HOLDING POWER: 900KG/F
MAGNETIC DIMENSION: 99MM X 177MM
HOLE CUTTING CAPACITY: 32MM
MAX. PLATE THICKNESS: 50MM
|
