WOOD CHIPPER SHREDDER 200MM PTO DRIVE

 New and improved website Freight Free

Enquiry
WOOD CHIPPER SHREDDER 200MM PTO DRIVE
Click on image for larger photo
Product Code: WC-8TM

WOOD CHIPPER SHREDDER 200MM PTO DRIVE.
3 POINT PTO WOOD CHIPPER. SWIVEL CHUTE
200MM(18")GREEN WOOD. CAPACITY-25-45HP
Border Image Border Image
Shop Price: $3,499.00
Web Price: $3,499.00  inc tax

Availability: In Stock
Quantity:
Weight: 480 KG
Border Image Border Image
3 POINT LINKAGE MOUNT SERIES 1 WITH POWER TAKE OFF OPERATION

TRACTOR REDUCTION BOX FEED TYPE (NOT HYDRAULIC)

200MM (8") GREEN

IDEAL HORSEPOWER REQUIRED - 25HP TO 45HP, 540 RPM

NOTE THIS UNIT IS SUPPLIED WITH A POWER TAKE OFF SHAFT FOR PTO OPERATION

THIS IS A SERIOUS PIECE OF MACHINERY FOR CHIPPING UP TO 200MM (8")

ASK OUR OPPOSITION THE FOLLOWING QUESTIONS:
- WHAT IS YOUR BLADE SIZE? OURS IS 200 X 60 X 9MM THICK CR12 STEEL CUTTING BLADE
- WHAT THICKNESS IS YOUR FLYWHEEL 20MM ??? OURS IS 25MM THICK & 600MM ROUND !!!
- WHAT IS THE THICKNESS OF THE BLADE BOX 6MM OURS IS 8MM !!!!

THERE ARE TWO ROLLERS THAT THE BRANCHES ARE FED THROUGH. THE TOP ROLLER IS THE PULLING ROLLER WITH LUGS ON IT AND IS HYDRAULICALLY POWERED FOR PULLING MATERIAL IN. THE SECOND ROLLER IS A SMOOTH UNPOWERED ROLLER TO ASSIST IN THE ALIGNMENT AND PROCESSING OF MATERIAL.

REMOVABLE LONG SAFETY KIT WITH EC APPROVAL.

REDUCTION GEARBOX FOR FEEDING - 4MM PER SECOND, ONLY FORWARD FUNCTION AND IS NOT REVERSABLE
PTO DRIVE SHAFT IS SUPPLIED WITH THIS UNIT

WORKING EFFICIENCY 7 ~ 8M 3/H

DIMENSION: 1118 X 1850 X 1350MM
DRIVE SYSTEM IS DIRECT DRIVE PTO WITH A SHEARBOLT
BLADE BOX THICKNESS IS 8MM
RADIUS OF BLADE DISC: 302MM
FLYWHEEL DIAMETER 600MM
FLYWHEEL THICKNESS: 25MM
FLYWHEEL TURNING SPEED: 1120/1490 RPM
WORKING EFFICIENCY: 7-8 3/H METRES CUBED
PTO TURNING SPEED: 540 TO 1000 RPM/MINUTE
POWER REQUEST: 25HP TO 45HP
MAXIMUM FEED DIAMETER: 200MM (8")GREEN TIMBER
CHIP SAWDUST THICKNESS: <4MM
NO. OF BLADES: 2
BLADE SIZE - 200 X 60 X 9MM THICK CR12 STEEL CUTTING BLADE
360 DEGREE FEED OUTLET ROTATION
BLADES MANUFACTURED USING CR12 MATERIAL

BEARING INFORMATION:
FLY WHEEL SHAFT BEARING UCF210 X2
PTO CONNECT BEARING UCP207 X2
FLY WHEEL BELT BEARING UCP210 X1
ROLLER BEARING UCFL204 X4

SHIPPING DIMENSIONS- 1100MM X 900MM X 1140MM
