Product Code:
TRAIL12X7FBTIP
TRAILER GAL 12X7 FLAT BED TIPPER 600MM
CAGE 4 WHEEL 10" ELECTRIC BRAKES,SLIDE
IN RAMPS -215R15 WHEELS, ATM 3500KG
|
|
|
|
|
Please enter a valid quantity |
|
|
|
|
 |
|
|
|
DESCRIPTION
12X7 FLATBED TIPPER TRAILER, W/ 600MM CAGE & 2000MM RAMPS
100X50X5MM RHS DRAWBAR, 1800MM LONG, W/ 2X13MM SAFETY CHAINS (STAMP AS4177-35)
100X50X5MM RHS LOWER CHASSIS FRAME,
100X50X4MM UPPER CHASSIS FRAME,
70X50X3MM RHS CROSSBAR 2.5MM CHECKER PLATE FLOOR,
2.5MM CHECKER PLATE MUDGUARD (BOLTED)
300MM HIGH SIDES, FOLD DOWN TYPE, REMOVABLE, 1.5MM FLAT PLATE STEEL W/ FOLDING DESIGN
1200MM HEADBOARD.
TAILGATES W/ FOLDING FLAT PLATE, REMOVABLE
50X50MM SOLID SQUARE AXLES BEAM, WITH 10INCH ELECTRIC BRAKE ON 4 WHEELS 6-STUDS
7 LEAF SPRING, EA. 60X8MM, ROCK ROLLER SUSPENSION
15INCH LIGHT TRUCK TYRE 215/70R15 WITH PAINTED RIM 6-STUDS (DOT&EMARK)
10INCH TOP WINDS JOCKEY WHEEL.
50MM BALL AU STANDARD ELECTRIC-BRAKE COUPLING
BREAKAWAY EMERGENCY BRAKE SYSTEM FITTED
LED TAIL LIGHTS AND MARKER LIGHTS WITH REFLECTORS
FLAT STYLE TRAILER PLUG
ATM 3,500KG
TARE. 1280
CARRYING.2220
TYRES. 215/70/15
|
View Complete Range:
|
TRAILERS
TRAILERS > TRAILERS - TANDEM AXLE
TRAILERS > TRAILERS - HYDRAULIC TIPPER
TRAILERS > TRAILERS - PLANT
|
|
|
