Product Code:
HPP12V/SA/11L
HYDRAULIC POWER PACK 12V S/ACTING 11 LIT
SINGLE ACTING OPERATED FROM CAB OR LEAD
SWITCH-1 LITER CAP- 12 VOLT-8.6 LPM FLOW
|
|
|
|
|
Please enter a valid quantity |
|
|
|
|
 |
|
|
|
2500 PSI FLYRATE DROPS AS BEING USED
2500 PSI 3.5 LITRES PER MINUTE
1500 PSI 6 LITRES PER MINUTE
DESCRIPTION:
SINGLE ACTING SOLENOID.
PUMP/MOTOR/RESERVOIR/VALVE
CHECK VALVE
2-WAY/2-POSITION NORMALLY CLOSED SOLENOID-OPERATED LOWERING-VALVE
EXTERNALLY ADJUSTABLE RELIEF-VALVE
WORKING PORT 3/8 NPT
HORIZONTAL MOUNTING STANDARD
REMOTE CONTROL HYDRAULIC SINGLE ACTING SWITCH
REQUIRED IS DC1097 OR 0993
2 BUTTON WITH 3 WIRES FOR POWER UP ONLY WILL LOWER ON ITS OWN WEIGHT
SPECIFICATIONS:
VOLUME LITRES: 8.3
MATERIAL: STEEL
SHAPE: SQUARE
VOLT: 12
OVERALL LENGTH- 668MM
ABOUT THIS ITEM
- HIGH-POWERED PERFORMANCE: OUR HYDRAULIC PUMP ADOPTS A 12V, 1.6KW DC MOTOR, DELIVERING A HIGH FLOW RATE OF UP TO 0.91GPM. WITH A 12-QUART TANK AND 16-20MPA OIL PRESSURE, THIS POWERHOUSE RELEASES A MAXIMUM PRESSURE OF 3200 PSI; THE DUMP TRAILER PUMP CAN EFFORTLESSLY HANDLE HEAVY VEHICLES AND MACHINERY, LIFTING THEM WITH EASE. EXPERIENCE THE POWER !
- QUICK LIFTING: THE HYDRAULIC POWER UNIT EMPLOYS A SINGLE-ACTING POWER MECHANISM, WHICH ENABLES A MORE STABLE AND RELIABLE LIFTING PROCESS. A BUILT-IN SAFETY RELIEF VALVE AUTOMATICALLY RELEASES PRESSURE IF THE LIMIT IS EXCEEDED, ENSURING A SAFER OPERATION WITH FEWER FAILURES.
- HASSLE-FREE SETUP: THE 12V HYDRAULIC PUMP ARRIVES PRE-ASSEMBLED. ADD HYDRAULIC OIL AND CONNECT THE POWER SUPPLY AND TUBING, AND YOU'RE READY TO START. VEVOR HYDRAULIC PUMP INCLUDES AN SAE#6 CONNECTOR, MAKING IT COMPATIBLE WITH METRIC AND AMERICAN INTERFACES FOR YOUR CONVENIENCE.
- BUILT TO LAST: OUR HYDRAULIC PUMP IS BUILT TOUGH. IT BOASTS ROBUST OVERALL SEALING, MINIMIZING THE RISK OF OIL LEAKS. THE RUST-PROOF SOLID METAL STEEL TANK ENSURES DURABILITY, EVEN IN HIGH-IMPACT SITUATIONS AND DAILY USE. IT'S ENGINEERED TO WITHSTAND THE RIGORS OF INSTALLATION ON HEAVY EQUIPMENT.
- VERSATILE APPLICATIONS: THIS SINGLE-ACTING HYDRAULIC PUMP ISN'T LIMITED TO ONE TASK. IT'S A VERSATILE WORKHORSE, SUITABLE FOR VARIOUS LIFTING AND STAMPING APPLICATIONS. FROM DUMP TRAILERS AND CONTAINER TRUCK TAILPLATES TO HYDRAULIC WOOD SPLITTERS, SMALL PRESSES, LIFTING PLATFORMS, SEMI-ELECTRIC PUSH TRUCKS, BUCKET TRANSPORTERS, AND MORE.
|
