Product Code:
TRAIL8X5GTAC
TRAILER 8 X 5 GALVANISED TANDEM AXLE.
40 X 40MM SQUARE AXLE BEAM-FORD BEARING
-ATM 2000KG-TARE 670KG 14"RIMS TYRES
|
|
|
|
|
Please enter a valid quantity |
|
|
|
|
 |
|
|
|
WELBILT BRAND TRAILER SIZE 8 X 5 GALVANISE BODY & TANDEM AXLE. [NO CAGE]
CAGE AVAILABLE FOR THIS UNIT SIZE - 600MM TALL, FRAME 30 X 30 X 1.5MM TUBE, 50 X 70 X 4MM MESH
LOOK AT THE FEATURES:
- ROPE RAILS
-1000KG RATED SPRINGS & AXLES @ 1200KG
- DRAWBAR - 1600MM LONG, 50 X 100 X 3MM RHS
- SAFETY CHAIN - 2 PIECES 10MM CHAINS AS4177-25 STAMPED WITH D SHAKLE 7/16"
-CHASSIS - 50MM X 50MM SQUARE TUBE, 2.5MM THICK
-CROSSBAR - 50MM SQUARE TUBE
-FLOOR THICKNESS - 2.5MM WITH CHECKERPLATE FULLY WELDED TO CHASSIS
-SIDE PANELS ON TRAILER - 300MM HIGH, 2.5MM FOLDING FLAT PLATE, DETACHABLE
-FRONT/REAR GUARDS - 1.5MM FOLDING FLAT PLATE, REMOVABLE
-MUDGUARDS - CHECKERPLATE WITH SMALL TRIANGLE STEP-UP PLATFORM AT REAR
-LATCH - CATCH FASTENER
-TIEDOWN BAR ALL ROUND
-FINISH - HOT DIP GALVANISING
-AXLE - 40 X 40MM SQUARE AXLE BEAM, FORD BEARING 12000KG CAPACITY
-FRONT DISC BRAKED WITH REAR LAZY AXLE
-SUSPENSION - 6 LEAF SPRING, EA. 60 X 6MM, ROCK ROLLER
-COUPLING - 50MM BALL, DISC OVERRIDE MECHANICAL-BRAKED, AUSTRALIAN STANDARDS
-LED WATERPROOF LIGHT SET
-TRAILER PLUG - 7 PIN FLAT
- JOCKEY WHEEL SWING UP - 6 INCH TOP WIND, LOAD 340KG (750LBS)- 2000 KG ATM
- GVM 2000KG
- TARE 420KG
- MAX LOAD 1580KG
-WHEELS & TYRES - 185/70R14 TYRE WITH 14" PAINTED POWDER COATED RIM
|
